HYDROELECTRIC PROJECT COCA ELDO SINCLAIR

Management and supervision of the contract to Coca Codo Sinclair for the engineering development, equipment and material supply, construction of civil works, assembly of equipment and start-up of the Coca Codo Sinclair Hydroelectric project.

• Storage capacity: 318,000 m³
• Drained basin area: 3,600 km2
• Maximum rate: 7,500 m3/s
• Design flow rate for two pressure pipes: 139.20 m3/sec each, with a length of 1,852 m and 1,946 m respectively
• Powerhouse: 26 m wide, 192 m long by 50 m high
• 608 m net drop
• Installed capacity: 1,500 MW
• Conduction tunnel that connects the reservoir with the powerhouse with a flow rate of 222 m3/s, a diameter of 9.10 m and a length of 24.8 km

The project consists of two dams, two spillways, a sand trap, a discharge pipe, and a conduction tunnel, the height of the main dam is 53.5 meters.

GENERAL INFORMATION
Location: Republic of Ecuador
Date: 2011 – 2018

LA YESCA HYDROELECTRIC PROJECT

Legal and technical assistance provided to the Comision Federal de Electricidad to follow up the demands and claims, as well as the administration of the diverse public work contracts associated with the construction of La Yesca Hydroelectric project.

• Storage capacity: 318,000 m³
• Drained basin area: 3,600 km2
• Maximum rate: 7,500 m3 / s
• Design flow for the pressure pipes: 139.20 m3/sec each, with a length of 1,852 m and 1,946 m respectively
• Powerhouse: 26 m wide, 192 m long by 50 m high
• 608 m net drop
• Installed capacity: 1,500 MW
• Conduction tunnel that connects the reservoir with the powerhouse with a flow rate of 222 m3 / s, a diameter of 9.10 m and a length of 24.8 km

The project consists of two dams, two spillways, a sand trap, a discharge pipe, and a conduction tunnel, the height of the main dam is 53.5 meters.

GENERAL INFORMATION
Location:Tepic, Nayarit, Mexico
Date: 2011 – 2012

EL CAJON - HYDROELECTRIC PROJECT

Supervision of the civil works associated to the construction of the Hydroelectric project El Cajon in Nayarit delivered to the Comision Federal de Electricidad.
Concrete face dam with a height of 194m.
Control structure with six radial gates supported by a concrete spillway that discharges into two covered channels. Maximum design rate of 15,915 m3 per second.
Intake work located on the right side, it communicates with an underground powerhouse with an installed capacity of 750 MW, two turbines Francis type of 375 MW capacity each. Plant connected to the national energy system with an annual production of 1,229 gwh.

GENERAL INFORMATION
Location: Tepic, Nayarit, Mexico
Date: 2003 – 2007

LUIS DONALDO COLOSIO MURRIETA (HUITES) HYDROELECTRIC PROJECT

Supervision and quality control of the Luis Donaldo Colosio Murrieta Hydroelectric project (Huites), in the state of Sinaloa.
Storage capacity of 4,568 million m³ to irrigate 446,000 hectares of crops using the river flow rate of the Rio Fuerte.
Concrete dam gravity-type with 166 m of high and 426 m long, with outlets and spillways, the latter with four radial gates on the spillway crest connected to the discharge channel. Spillway's design rate of 22,445 m³ per second.
Intake work and hydroelectric plant located on the right side of the dam. Hydroelectric plant with an installed capacity of 400 MW, two turbines Francis type of 200 MW each. Plant connected to the national energy system, eastern sector, with an annual electric production of 875 GHW.

GENERAL INFORMATION
Location: Sinaloa, Mexico
Date: 1992 – 1996
